Extender
4K HDMI KVM 120M Extender transmitter:
Power: DV 5V power adapter
Output: HDMI loop out signal output port
Input: HDMI signal input port
IR-TX: Infrared transmitter connect port
USB-PC: USB output, connect computer
Ethernet: Cat5/6 ethernet port
Power: Power signal light
R/L: Stereo output
Power: DV 5V power adapter
Output: HDMI signal output port
IR-TX: Infrared transmitter connect port
USB1-2: USB mouse/keyboard input
Ethernet: Cat5/6 ethernet port
Power: Power signal light
R/L: Stereo output
IR-TX: Infrared transmitter connect port
USB1-2: USB mouse/keyboard input
Ethernet: Cat5/6 ethernet port
Power: Power signal light
R/L: Stereo output
